Automatic drill Alzmetall

According to the official factory documentation and technical historical archives of the manufacturer, the Abomat 60 model (often in the 50/60 configuration) is characterized by the following parameters:
Drilling capacity: Up to 65 mm in steel (St 60), ie up to 75 – 80 mm in cast iron (GG 20).
Threading capacity: Extremely powerful drive enables threading up to M68 in steel and up to M72 in cast iron.
Tool spindle: Robust ISA 40 taper (heavy-duty SK 50 for automatic tool changer available on some variants).
Spindle travel (Z-axis): Up to 700 mm of travel, which allows drilling deep holes and machining tall pieces.
Spindle speed range: Continuously adjustable (depending on gearbox) in the range from 63 to 1600 rpm.

Specifications:

Brand: Alzmetall, model ABOMAT 60.
Work table: 700 x 800 mm, with tool holder.
Chuck stroke: 480 mm.
Engine power: 7.5 KW (10 HP), speed 1400 rpm.
Drive: via a manual gearbox in 12 degrees.
Drilling speed: from 23 rpm to 910 rpm.
Drilling capacity (MK5): Ø 65 mm (in steel).
Feeds: 0.1 – 0.7 – 0.14 – 0.2 – 0.28 – 0.4 – 0.56 mm/rev.
Machine dimensions: 830 mm x 1600 mm x 2800 mm.
Year of manufacture: 1980.
Used, imported from the EU.

Automatic Drill Alzmetall

1 of 6

Automatic drill Alzmetall is located in Mačvanska Mitrovica, Žarka Vucinića street 32 b (part of the city of Sremska Mitrovica), Serbia. The machine is in good condition and you can test it in operation. Transportation of the machine is at the client’s expense, and after purchasing from our company, the Automatic metal drill will be load onto the client’s vehicle free of charge. “Apocalypse” LLC has over 2,500 used machines in stock. Machines are mostly Italian made, of iron cast. We offer complete lines for the production of wooden crates of the Corali brand. «Apocalypse» LLC offers you complete lines for the production of: furniture, pellets, pallets, wooden doors and windows, as well as parquet. Be our guests, and let’s work together for mutual benefit.
