CNC machining center.

This CNC machine features a gantry (bridge) design, primarily used for precision machining of materials such as aluminum (ALU) and PVC. This robust industrial machine, imported from Italy, is designed for high stability and rigidity during milling and drilling, which is crucial for achieving high precision when machining longer and more complex profiles.

CNC machining center

1CNC Machining Center – Technical Specifications:

Bridge-type machining center, for processing PVC, ALU…
Dimensions of the work table: 1070 x 600 mm.
Brand: M ZERO, model VPC1000
Year of manufacture: 1996.
Portal structure:
Electrospindle: ISO 40 spindle.
30 tool change places
Type CNC: SELCA 3045.
Shaft travel:
X = 1084 mm.
Y = 558 mm.
Z = 500 mm.
Working progress: 8000 mm/min.
Fast insertion: 18000 mm/min.
Cone attack ISO 40, rpm 8000,
Installed power: 22 KW.
Machine weight: 5800 kg.
Machine dimensions: 2300 x 2400 x 2900 mm.
Used, imported from Italy.

Most commonly used in the following industries:

Mold and tool manufacturing: Due to its stability and high precision, it is ideal for making molds for plastic injection molding or metal casting.
Aluminum and PVC profile production: Used in carpentry and facade manufacturing for precise drilling and milling of holes on long profiles.
Automotive and mechanical engineering: For serial or individual production of housings, flanges, gears, and other precision machine parts.

CNC machining center is located in Mačvanska Mitrovica, Žarka Vučinića Street 32 b . (part of the city of Sremska Mitrovica), Serbia. The machine is in good condition and can be tested in operation. The transportation of the machine is done at the customer’s expense, and after the purchase from our company, the bridge-type machining center will be loaded onto the customer’s vehicle free of charge. “Apocalypse” LLC has over 2,500 used, refurbished machines in stock. The machines are mostly Italian-made, cast iron. We offer complete lines for the production of wooden crates of the Corali brand. Comprehensive production line for: furniture, pellets, pallets, wooden doors and windows, as well as parquet.
